Cabinet Hardware Drilling Jig

A versatile drilling and marking jig that assists in the accurate and repetitive installation of cabinetry handles and knobs on a wide variety of door and drawer fronts.

Steel Drilling Guides

Protective Rubber Over Mould

Quick 3 Stage Set-Up

Reversible Design

Self-Centering Scales


Key Applications

Accurate, fast, and repetitive installation of door handles and knobs across a range of door and drawer sizes.

Removes the need for measuring and marking in the traditional way.


Features

Self-Centering Scales with both imperial and metric options, remove the need for measurement calculations.

Reversible Design for switching between left and right-hung doors.

Protective Rubber Over-Mould prevents damage to doors and drawers when positioning and using the jig.

Quick 3-Stage Setup allows the jig to be set in seconds with a standard screwdriver.

4mm Tool-Steel Drilling Guides provide fast, accurate hole centres.

Sliding Top Guide accommodates handle insets from 30mm to 120mm from the top/edge of the door/drawer.

7

Sliding Edge Guide accommodates door and drawer sizes up to 600mm wide.

Polymer Construction delivers precision and durability.

7

Reversible Design

T


Self-Centering Scales

T


Quick 3-Stage Set-Up

T

Jig Parameters

T


Details

  • Self-Centering Scales with both imperial and metric options, remove the need for measurement calculations.

  • Reversible Design for switching between left and right-hung doors.

  • Protective Rubber Over-Mould prevents damage to doors and drawers when positioning and using the jig.

  • 4mm Tool-Steel Drilling Guides provide fast, accurate hole centres.

  • Quick 3-Stage Setup allows the jig to be set in seconds with a standard screwdriver.

  • Sliding Top Guide accommodates handle insets from 30mm to 120mm from the top/edge of the door/drawer.

  • Sliding Edge Guide accommodates door and drawer sizes up to 600mm wide.

  • Polymer Construction delivers precision and durability.


Featured Products

CAB/JIG/A
Cabinet Hardware Drilling Jig

A versatile drilling/marking jig that assists in the accurate and repetitive installation of cabinetry handles and knobs on a wide variety of door and drawer fronts.
