U*KWJ650 - Kitchen Worktop Jig 25 1/2 inch c/w Peninsular Cut

U*KWJ650
CA$120.21

Stock Level In Stock

Tradesman work top jig for up to 25 1/2 inch worktops.

  • Hard wearing CNC machined Compact Grade High Pressure Laminate 15/32 inch thick jig that cuts both parts of the joint in 15 minutes including setting up.
  • Left hand and right hand corners, 15 3/4 inch radius peninsular joint, 1 3/8 inchkitchen door hole.
  • Fixed lengths for 23 5/8 inch, 24 1/4 inch, 25 inch and 25 1/2 inch wide worktops.
  • Cuts up to 1 37/64 inch thick worktops with or without anti-drip postformed edge.
  • Two open ended bolt recesses (dog bone style) for 5 29/32 inch bolts.
  • 25/64 inch diameter plastic pins with tapered shoulder for tight fit provides three point pin contact to ensure ease of setting up.
  • Pins made from ABS plastic for strength.
  • Jig requires:
  • A portable plunge router with 1/2 inch shank capacity and minimum 1300 watts.
  • A template guide bush with 1 3/16 inch outside diameter ref. U*GB30.
  • A TCT router cutter with 1/2 inch diameter and 2 inch cut length.
  • Two clamps.
Length
34 41/64 inch
Width
8 25/32 inch
Thickness
15/32 inch
Weight
7lb 4oz
Female cut material width loss (inset)
1 19/64 inch
Curved Peninsular Radius
15 3/4 inch
Bolt recesses
2
Guide bush
1 3/16 inch
Plunge router
1/2-inch (min. 1300 watts)
Cutter
1/2 inch x 1 31/32 cut
Clamps
Two

no spare products

Videos

The 650mm Kitchen Worktop Jig - KWJ650

This video demonstrates the compact 650mm worktop jig in action.
